WHERE CHEMICAL RESISTANCE MEETS THERMAL ENDURANCE

Textrov FluoroCoat by Supertech Fabrics is a specialized range of PTFE-coated technical textiles engineered for high-demand industrial environments. Whether you’re dealing with corrosive gases, extreme heat, or sticky materials — FluoroCoat delivers unmatched reliability, cleanliness, and longevity.

WHY CHOOSE FLUOROCOAT?

Use of diverse fluoro chemicals and formulation for diverse application.
Choice of primary function from acid-resistance, anti drip, cleanroom-safe, and food-grade options.
Use of high quality Fluoro chemical resin.
Norms specific formulations.

TYPES OF FLUOROCOAT APPLICATIONS

At Textrov FluoroCoat, handling of fluoro polymer using various techniques that deliver
different products.

Fluoro impregnation coating of fibres.
Fluoro one-side coating of surface.
Fluoro membrane (ultra/nano porous structure).
Fluoro ePTFE membrane (micro-porous structure).
Fluoro mixed formulation with other chemistries.

Advantages of Fluoro Coating

Superior chemical resistance
Chemically inert to HF, HCl, SO₂, Cl₂, etc.
Excellent heat and flame resistance
Non-stick and low friction surface
Excellent weather and UV resistance
Waterproof and hydrophobic properties
Antimicrobial and mold resistance
High tensile and tear strength
Non-toxic, non-VOC
Safe for medical and food applications
Electrical insulation properties
Low maintenance and long service life
High performance in extreme conditions

TECHNICAL PERFORMANCE DATAPOINTS

Fluoro chemicals versatility best explored in combination with various substrates and application case. Responsible use of fluoro chemicals.

Parameter	Typical Values / Description
Operating Temperature	–150°C to +260°C (Custom: up to 290°C)
Chemical Resistance	Class A – Resistant to HF, HCl, SO2; Tested with waste chemical agents (400x500 in cm)
Tensile Strength (0°C / 30°C)	Up to 25,000 N/5cm (depending on base fabric)
Tear Strength	> 300 N (Higher in aramid-based fabrics)
Dielectric Strength	> 10 kV
Surface Resistivity (ESD)	10⁴–10⁹ Ω on antistatic variants
Moisture Resistance	< –9.01% absorption (highly hydrophobic)
Abrasion Resistance (Taber)	Excellent (variant-specific, typically Taber loss < 100 mg / 1000 cycles)
Friction Coefficient	0.08–0.15 (non-stick surface)
Alkali Resistance	Excellent (NaOH, KOH exposure safe)
UV Resistance	High – stable in outdoor / high-exposure conditions
Hydrophobicity	Water contact angle >110° (Cleanroom & food-grade variants)
Permeability	< 1% vapor/gas/moisture penetration
Thickness Range	0.08 mm – 1.2 mm
Weight (GSM)	100–1000 gsm (depending on construction)
Coating Types	Single-side, Dual-side, Mesh-reinforced, Multi-layer
Color Options	Brown, Grey, White, Black (Custom colours on request)
Certifications	FDA 21 CFR 177.1550, EC 10/2011, RoHS, REACH, ISO 14644, USP Class VI, UL 94, ASTM E84, EN 45545 (variant-specific)
